Product Overview
The Toro 72504 GrandStand® 48″ 22 HP 726cc is a Toro stand-on mower listed in the 407 Equipment Sales Lawn Care catalog. It is identified by SKU 407ES-023972. Key specifications for this configuration include engine brand: Kawasaki; cutting width: 48″; engine power: 22 HP; engine displacement: 726cc.
Key Features
- SKU: 407ES-023972
- Engine Brand: Kawasaki
- Cutting Width: 48″
- Engine Power: 22 HP
- Engine Displacement: 726cc
- Maximum Speed: 10 mph
- Fuel Capacity: Gas/10.5 gal
- Weight: 890 lbs.
- Height of Cut: 1″ – 5″ in 1/4″ increments
- Adjustable Discharge Baffle: Standard
- Air Filter: Heavy-Duty Canister Air Cleaner
Product Highlights
- Operator design: the source emphasizes a comfort-focused seating and control layout for extended mowing sessions.
- Terrain design: a low center of gravity supports stability on demanding ground.
Product Specifications
| Brand | Toro |
|---|---|
| Engine Brand | Kawasaki |
| Model / MPN | 72504 |
| SKU | 407ES-023972 |
| Cutting Width | 48″ |
| Engine Power | 22 HP |
| Engine Displacement | 726cc |
| Maximum Speed | 10 mph |
| Fuel Capacity | Gas/10.5 gal |
| Weight | 890 lbs. |
| Height of Cut | 1″ – 5″ in 1/4″ increments |
| Adjustable Discharge Baffle | Standard |
| Air Filter | Heavy-Duty Canister Air Cleaner |
| Blade Tip Speed | 18,500+ ft/min |
| Blade Type | .25″ heat-treated steel |
| Carrier Frame | 3″ x 1.5″ x 12 gauge |
| Caster Tires | 11″ x 5″-5″ flat free semi-pneumatic |
| Clutch | Electromagnetic |
| Deck Design | 80-grade 7-gauge 48″ TURBO FORCE® w/bull-nose bumper |
| Discharge Chute | Rubber |
| Drive System | Pumps (10cc/rev) & Wheel Motors (10 cir) |
| Drive Tires | 20″ x 10.5″- 8″ |
| Engine | 22 hp (16.4 kw) Kawasaki FX 726cc |
| Ground Speed | Up to 10 mph forward |
| Hour Meter | Standard |
| Hydraulic Fluid | Premium synthetic |
| Spindle Bearings | Greaseless ball bearings |
| Spindle Housing | 9″ diameter cast aluminum |
| Steering Controls | Twin lever |
Application and Compatibility
Confirm deck width, engine configuration, controls, transport width, and operating clearances for the intended property.
Before You Order
- Use SKU 407ES-023972 as the primary ordering reference.
- Confirm that the published configuration, included equipment, capacities, dimensions, and power system match the intended application.
- For replacement parts, accessories, bundles, or attachments, verify compatibility using the equipment model and serial-number range.
- Plan delivery access, unloading equipment, storage space, and any assembly or dealer setup required for the product.
Need more technical details or compatibility information? Contact our team and we will help you find the right fit.
