Product Overview
Makinex Generator 23kW Generator is a generator designed for portable or standby jobsite power for tools, lighting, and equipment. The Generator 23kW configuration pairs 23 kW output class, 110V single phase; 480V three phase voltage, and 60 Hz frequency.
Key Features
- Compact 480V three-phase generator for concrete and flooring equipment.
- Independent 110V auxiliary and 480V circuits allow simultaneous mixed-load use.
- Vanguard V-Twin engine and radial flux alternator support high output in a compact frame.
- Four-wheel portable design fits into tighter work areas than tow-behind units.
- 13.2 gal tank and 573 lb dry weight support commercial jobsite planning.
- No voltage selection is needed for the appropriate outlets.
Product Specifications
- Store SKU
- GPE211037
- Manufacturer Product Code
- GEN-23P-MS-480
- Equipment Type
- Portable dual-phase gasoline generator
- Output Class
- 23 kW
- Voltage
- 110V single phase; 480V three phase
- Frequency
- 60 Hz
- Three-Phase Power
- Max 25 kW / continuous 22.5 kW
- Single-Phase Auxiliary Power
- Max 2.2 kW / continuous 2 kW
- Three-Phase Current
- Max 30 A / continuous 27 A
- Single-Phase Auxiliary Current
- Max 20 A / continuous 18 A
- Engine Type
- Twin-cylinder air-cooled petrol
- Engine Model
- Vanguard 61G277
- Displacement
- 993 cc
- Starting System
- Electric key start
- Fuel Economy
- 1.59 gal/hr at 50% load
- Fuel Tank
- 13.2 gal
- Noise Level
- 72 dB no-load at 7 m
- Dry Weight
- 573 lb
- Dimensions
- 43 x 25 x 40 in
- Warranty
- 3-year warranty listed by Makinex for 23kW generators
Applications & Purchase Considerations
The Generator 23kW is best matched to portable or standby jobsite power for tools, lighting, and equipment where the job requires 23 kW output class, 110V single phase; 480V three phase voltage, and 60 Hz frequency.
- Site utility or fuel: 110V single phase; 480V three phase
- Confirm delivery ZIP code and carrier-accessible receiving details before checkout
Product Identification
| Brand | Makinex |
|---|---|
| SKU | 407ES-005316 |
| MPN / Model | GPE211037 |
| Condition | New |
| Division | Generators |
| Primary Category | Generators |
Before You Order
Confirm that model GPE211037, the listed capacity or working range, power requirements, dimensions, and site-delivery needs match your application. Only specifications stated in this listing should be used for purchase planning.
Need more technical details or compatibility information? Contact our team and we will help you find the right fit.
